Nawar

/ Nawar / Downlight Series / Product /

Further versions on request

Light colours: 2700K or 4000K with CRI ≥ 90
Do you have further requirements with the product?

Please contact the consultant team in the following VACE office:
Call an VACE consultant: 86 +760 22559792
ADD:NO.11, First Street of Wencheng RD, Xiaolan Town, Zhongshan City

Structure and characteristics
Lighting technology
8885 318
Light source：
COB
LED Power：
40W
Beam angle：
60°
CCT：
3000K / 4000K / 6000K
LED lumens：
3410lm
Color rendering index：
Ra≥80
Operating temperature：
-20-+40℃
The output voltage：
36V
Output current：
950mA
dimension：
Ø200
Cut out：
Ø220* 90
Pictures of application
Service
Product overview120V/60Hz, 277V/60Hz

Light source

  COB

LED Power

  40W
  30W
  18W
  12W

Beam angle

  60°

CCT

  3000K
   6000K
   4000K

LED lumens

  3410lm
  2700lm
  1440lm
  1040lm

Housing colour
